MP2000

Radius: 4.9 to 6.4m
Flow rate: 1.18 to 6.40 l/m

SKU: MP2000 Category: Tags: ,

MP2000

Multiple Rotating Streams Use Less Water and Provide Healthier Growth

The revolutionary MP Rotator features a unique, multi-trajectory rotating stream delivery system that achieves water-conserving results. Rather than simply “spray” water onto landscapes, MP Rotators deliver multiple streams of water at a steady rate. This slower application rate allows water to gently soak into the soil and achieves an even distribution throughout the area being irrigated. This increased efficiency results in 30% less water use when compared to traditional sprays and significantly reduces wasteful runoff. The MP Rotator can be installed onto any conventional spray head body or shrub adapter, transforming them into high uniformity, low precipitation rate sprinklers with matched precipitation at any arc and any radius.

The MP Rotators are a great choice for new systems, as they provide immense range flexibility (from 2.5 to 9.1m radius), decrease material costs, and provide better system efficiency. MPs are also perfect for revitalizing older systems-a retrofit can solve both low pressure and poor coverage problems.

Operating Specifications

Radius: 4.9 to 6.4m
Flow rate: 1.18 to 6.40 l/m
Recommended pressure range: 1.75 to 3.75 bars
Precipitation rates: 10 mm/h

Warranty period: 3 years

Model

MP200090 90° to 210° MP2000210 210° to 270° MP200090_360o

MP200090
90° to 210°

MP2000210
210° to 270°

MP2000360
360°

Operating Specifications

Radius: 4.9 to 6.4m

Flow rate: 1.18 to 6.40 l/m

Recommended pressure range: 1.75 to 3.75 bars

Precipitation rates: 10 mm/h

Download Documents

MP Rotator Brochure: Brochure-MP-Rotator

MP Rotator Catalog: Catalog-MP-Rotator

MP Rotator Product Instruction Guide: Product-Instruction-Guide-MP-Rotator

MP Rotator Installation: Installation-MP-Rotator
