PGP Ultra

Radius: 4.9 to 14.0 m
Flow Rate: 0.07 to 3.23 m3/hr

SKU: PGP Ultra Category: Tags: , ,

PGP Ultra

The PGP Ultra takes the foundation of the best-selling PGP Rotor and raises the bar with a variety of new features developed over three decades of research, customer feedback, and lab testing. Among the most notable improvements of the PGP Ultra is its non-strippable drive and automatic arc return. These two features work to allow the turret to be turned without causing damage, and return the turret to its original arc regardless of where it is turned. Other advanced features include 34 nozzle options with several radius choices, and a headed slot and set screw. The diversity of the PGP Ultra offers system installers an array of efficient options on any site.

Operating specifications

Radius: 4.9 to 14.0 m
Flow Rate: 0.07 to 3.23 m3/hr
Recommended pressure range: 1.7 to 4.5 bar; 170 to 450 kPa
Operating pressure range: 1.4 to 7.0 bar; 140 to 700 kPa
Precipitation rates: 10 mm/hr approx
Nozzle trajectory: 13 degrees approx

Warranty period: 5 years

Model

Operating Specifications

Bán kính: 4.9 đến 14.0m

Lưu lượng: 0.07 đến 3.23 m3/giờ; 1.2 đến 53.8 lít/phút

Dải áp suất làm việc: 1.7 đến 4.5 bar; 170 đến 450 kPa

Dải áp suất chịu đựng: 1.4 đến 7.0 bar; 140 đến 700 kPa

Lượng nước tưới: 10 lít/m2/giờ

Download Documents

PGP Ultra Brochure: Brochure-PGP Ultra-Rotor

PGP Ultra Catalog: Cutsheet-catalog-PGP Ultra-Rotor

PGP Ultra Installation: Installation-PGP Ultra-Rotor
