Pro-Spray Fixed Arc Nozzle

Radius: 1.1m to 5.2m
Flow Rate: 0.02 to 0.60 m3/hr

SKU: Fixed Arc Category: Tag:

Pro-Spray Fixed Arc Nozzle

When Precision is Imperative, Pro Fixed Nozzles Are the Solution

Hunter Pro Fixed Nozzles are designed to offer the most reliable, precise fixed-arc spray solution possible. Because of their sturdy construction and outstanding performance reputation, Hunter fixed nozzles have become increasingly popular with contractors. Choose any standard or odd angle, and Pro Fixed Nozzle configurations deliver uniform distribution from all sides. The optimum droplet size minimizes misting and maximizes coverage. Five radius ranges are available, and each can be reduced for fine-tuning. Finally, our nozzles are color-coded for easy at-a-glance radius identification.

Operating specifications

Radius: 1.1m to 5.2m
Flow Rate: 0.02 to 0.60 m3/hr; 0.30 to 10.01 l/min
Operating pressure range: 1.0 to 2.5 bar; 100 to 250 kPa
Precipitation rates: 41 mm/hr approx

Warranty period: 2 years

Model

Nozzle_fixed_arc_model

Operating Specifications

Radius: 1.1m to 5.2m

Flow Rate: 0.02 to 0.60 m3/hr; 0.30 to 10.01 l/min

Operating pressure range: 1.0 to 2.5 bar; 100 to 250 kPa

Precipitation rates: 41 mm/hr approx

Download Documents

Fixed Arc Nozzles Catalog:  Catalog-fixed-arc-nozzles
